Quadralux Q2

Quadralux Q2 - LS9120

一种小型建筑投光灯, 设计融合了先进技术和优良性能

配制这款产品 Features 产品配置附件

产品总览

Quadralux Q2 是⼀种⼩型建筑标准射灯，设计融合了了先进技术和优良性能. 有⽩白光、彩⾊色光和可调⽩白光光引擎可供选择, Quadralux Q4 配有 EasyGlowTM 视觉舒适技术和 CoolDriveTM 热管理理技术. PowerSyncTM 技术可通过常规协议来实现⾼高精密度数字化控制。特有的安装固定装置和眩光控制组件使得产品可以安装于多个⽅方向. 如今, 灯光界的专家们在定制型和标准型LED产品⽅方⾯面有了了更更多的选择, 也有了了更更⼴广阔的创新可⾏行行性.

减少光透过光学元件后的分散，减少光束中的光条，缩短混⾊色距离

配件
LS6201	附件支架
LS6202	网状防眩光栅格
LS6203	45° 防眩光罩
LS6204	定制防眩光罩
LS6301	4.0" (106mm) 接线盒底座/表面安装底座
LS6302	3.0" (76mm) 圆柱扣件
LS6303	4.0" (102mm) 圆柱扣件
LS6304	4.5" (114mm) 圆柱扣件
LS6305	5.0" (127mm) 圆柱扣件
LS6306	2 3/8" x 4.0" (60mm x 104mm) Tenon支架
LS6307	3.5" x 6.0" (89mm x 147mm) Tenon支架

Features

Lumen Output 3,340 lm Power Consumption 33 W Typical Lifetime (TM21 Reported) > 60,000 hours @ 50°C Ambient (B10, L90, TM21 Reported) Typical Lifetime (TM21 Projected) 179,506 hours @ 50°C Ambient (B10, L90, TM21 Projected) Input Voltage International: 220-240 Vac, 50 Hz | North America: 120/277 Vac, 6 Control Interface Lumascape PowerSync Control Protocols DMX/RDM, Artnet (Ethernet Based), PWM, 0-10 V (sink or source) IP Rating IP66 / IP67 (Passes IP68 Test) IK Rating IK8 Vibration Resistance 3G Rating (ANSI C136.31) Compliance

Color Options Warm White

Data Sheet

产品配置

附件


Control
LS6540	PowerSync Data Injector, Line Voltage, Generation 2

Wiring
LS6402C-PS	Leader Cable, Line Voltage, 4-Core, PowerSync
LS6402C-2.5-PS	Leader Cable, Line Voltage, 4-Core, PowerSync, 2.5 mm²
LS6404C-PS	Jumper Cable, Line Voltage, 4-Core, PowerSync
LS6404C -2.5-PS	Jumper Cable, Line Voltage, 4-Core, PowerSync, 2.5 mm²

Glare Control
LS6201	Accessory Holder
LS6202	Cross Hatch Louver
LS6203	45° Visor
LS6204	Custom Visor

Mounting
LS6301	4.0" (106mm) Junction Box Adaptor / Surface Mounting Kit
LS6302	3.0" (76mm) Pole Clamp
LS6303	4.0" (102mm) Pole Clamp
LS6304	4.5" (114mm) Pole Clamp
LS6305	5.0" (127mm) Pole Clamp
LS6306	2 3/8" x 4.0" (60mm x 104mm) Tenon Adaptor
LS6307	3.5" x 6.0" (89mm x 147mm) Tenon Adaptor
LS6221-06	6" (152 mm) Stand-Off Bracket
LS6221-12	12" (305 mm) Stand-Off Bracket
LS6221-18	18" (47 mm) Stand-Off Bracket

下载

Data Sheet 安装手册

BIM Files LS9120 ZIP (3.56 M) DXF Files LS9120 ZIP (325.27 KB) Product Flyer Q2 & Q4 PDF (148.97 KB) CAD资料 Link

技术专利

Product Configurator

LS9120 _ _ _ _ _ _ _ _ _

登录查询价格

重设为默认清除选择添加

Customise Quadralux Q2 below

Light Engine

Required

30 W (30)

LED Type

Required

Designer (D)

Ideal for applications where colour consistency and colour over angle are most important (e.g., grazing and accent lighting)

Light Source

Required

Static White (827)

2,700 K (80 CRI, 3 SDCM)

Static White (830)

3,000K (80 CRI, 3 SDCM)

Static White (835)

3,500K (80 CRI, 3 SDCM)

Static White (840)

4,000 K (80 CRI, 3 SDCM)

Static White (750)

5,000K (70 CRI, 3 SDCM)

Dynamic Colour (4CA)

RGBA

Dynamic Colour (4BW)

RGBW with Royal Blue

Tunable White (2WT)

2,700 K - 6,500 K

Connection Type

Required

Single entry (84)

For connection to the supply circuit via flexible cable, up to 1.8m (6ft) in length. Single entry.

Single entry (77)

For connection to the supply circuit via Lumascape connection system with IP68 rated connectors. This method allows for tool free final connection to the luminaire.
